Item

Parameter

Pixel

Physical pixel pitch: 8 mm

Pixel configuration: 1R1PG1PB

LED

Wave

Brightness

Packing

R

620-625nm

600mcd

SMD-3535

G

520+/_1.25nm

1350mcd

SMD-3535

B

470+/_1.25nm

200mcd

SMD-3535

Module

Module resolution: 32 x 16 pixels

Module size: 256 x 128 mm

Electricity

parameter

Brightness: 6000 nits

Brightness adjusted: 100 grade by software, or by Auto-optic induced

Color processing: 16bit

Display color: 280 trillion

Color temperature(k): 5000 — 9500 (choice by user)

Physical density: 15625 pixels/m²

Whole display flatness: ≤ 1mm juncture

Best view distance: ≥ 5m

Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ～ +85℃ Working temperature: -20℃ ～ +50℃

Driving method: Constant driving current Scan: 1/4

Refresh frequency: ≥ 1900Hz

Frame rate: ≥ 60Hz

Humidity(RH): ≤ 90～95%

Protection grade: IP64

Working Voltage: DC 5V

Power supply: AC 110 / 220V, 50/60Hz

Average power consumption:300w/m²

Max power consumption: 700w/m²

MTBF: 10, 000 hours

Screen lifetime: 100, 000 hours

Control system

Control system: Linsn / Nova

Signal interface: DVI

Communication distance: Internet cable: ≤120m   Fiber cable: 1000m

Signal transfer mode: Pixels to pixels display synchronized
