Item

Parameter

Pixel

Physical pixel pitch: 4.81 mm

Pixel configuration: 1R1PG1PB

LED

Wave

Brightness

Packing

R

620-625nm

55mcd

SMD-2020

G

520+/_1.25nm

155mcd

SMD-2020

B

470+/_1.25nm

22mcd

SMD-2020

Module

Module resolution: 52 x 52 pixels

Module size: 250 x 250 mm

Cabinet

Cabinet resolution: 104x208 pixel

Cabinet size: 500 x 1000 x 80mm

Cabinet density:21632 pixels

Weight: 15Kg

Module quantity:8pcs=2(w)x4(h)

Average power:180W

Material: Die Casting Aluminum

Max power consumption: 370W

Electricity

parameter

Brightness: 1000 - 1200 nits

Brightness adjusted: 100 grade by software, or by Auto-optic induced

Color processing: 16bit

Display color: 280 trillion

Color temperature(k): 5000 — 9500 (choice by user)

Physical density: 43264 pixels/m²

Whole display flatness: ≤ 1mm juncture

Best view distance: ≥ 3m

Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ～ +85℃ Working temperature: -20℃ ～ +50℃

Driving method: Constant driving current Scan: 1/13

Refresh frequency: ≥ 1900Hz

Frame rate: ≥ 60Hz

Humidity(RH): ≤ 90 ～ 95%

Protection grade: IP31

Working Voltage: DC 5V

Power supply: AC110 / 220V, 50/60Hz

Average power consumption: 380 w/m²

Max power consumption: 750 w/m²

MTBF: 10000 hours

Screen lifetime: 100000 hours

Control

system

Control system: Linsn / Nova

Signal interface: DVI

Communication distance: Internet cable: ≤ 120m   Fiber cable: 1000m

Signal transfer mode: Pixels to pixels display synchronized
