Item

Parameter

Pixel

Physical pixel pitch: 2 mm

Pixel configuration: 1R1PG1PB

Wave

Brightness

Packing

R

620-625nm

20mcd

SMD-1010

G

520+/_1.25nm

30mcd

SMD-1010

B

470+/_1.25nm

5mcd

SMD-1010

Module

Module resolution: 160 x 80 pixel

Module size: 320 x 160 mm

Electricity

parameter

Brightness: 900 nits

Brightness adjusted: 100 grade by software, or by Auto-optic induced

Color processing: 16bit

Display color: 280 trillion

Color temperature(k): 5000 — 9500 (choice by user)

Physical density: 250000 pixels/m²

Whole display flatness: ≤ 1mm juncture

Best view distance: ≥ 3m

Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ～ +85℃ Working temperature: -20℃ ～ +50℃

Driving method: Constant driving current

Refresh frequency: ≥ 3000Hz

Frame rate: ≥ 60Hz

Humidity(RH): ≤ 90 ～ 95%

Protection grade: IP30

Working Voltage: DC 5V

Power supply: AC110 / 220V, 50/60Hz

Average power consumption: 300 w/m²

Max power consumption: 700 w/m²

MTBF: 10000 hours

Screen lifetime: 100000 hours

Control

system

Control system: Linsn/Nova

Signal interface: DVI

Communication distance: Internet cable: ≤ 120m   Fiber cable: 1000m

Signal transfer mode: Pixels to pixels display synchronized
