Item

Parameter

Pixel

Physical pixel pitch: 5 mm

Pixel configuration: 1R1G1B

LED

Wave

Brightness

Packing

R

620-625nm

450mcd

SMD-2727

G

520+/_1.25nm

680mcd

SMD-2727

B

470+/_1.25nm

100mcd

SMD-2727

Module

Module resolution: 64 x 32 pixels

Module size: 320 x 160 mm

Electricity

parameter

Brightness: 5500 nits

Brightness adjusted: 100 grade by software, or by Auto-optic induced

Color processing: 16bit

Display color: 280 trillion

Color temperature(k): 5000 — 9500 (choice by user)

Physical density: 40000 pixels/m²

Whole display flatness: ≤ 1mm juncture

Best view distance: ≥ 5m

Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ～ +85℃ Working temperature: -20℃ ～ +50℃

Driving method: Constant driving current

Refresh frequency: ≥ 1300Hz

Frame rate: ≥ 60Hz

Humidity(RH): ≤ 90～95%

Protection grade: IP65

Working Voltage: DC 5V

Power supply: AC 110 / 220V, 50/60Hz

Average power consumption:350w/m²

Max power consumption: 750w/m²

MTBF: 10, 000 hours

Screen lifetime: 100, 000 hours

Control

system

Control system: Linsn/Nova

Signal interface: DVI

Communication distance: Internet cable: ≤120m   Fiber cable: 1000m

Signal transfer mode: Pixels to pixels display synchronized
