Item

Parameter

Pixel

Physical pixel pitch: 1.667mm

Pixel configuration: 1R1PG1PB

Wave

Brightness

Packing

R

620-625nm

15mcd

SMD-1010

G

520+/_1.25nm

50mcd

SMD-1010

B

470+/_1.25nm

6mcd

SMD-1010

Module

Module resolution: 144 x 144 pixel

Module size: 240 x 240mm

Cabinet

Cabinet resolution: 288 x288 pixel

Cabinet size: 480 x 480 x 65mm

Cabinet density: 82944 pixels

Module quantity:4pcs=2(w)x2(h)

Material: Die casting aluminum

Weight: 5.2Kg

Average power consumption: 50W

Max power consumption: 100W

Electricity

parameter

Brightness: 800 nits

Brightness adjusted: 100 grade by software, or by Auto-optic induced

Color processing: 16bit

Display color: 280 trillion

Color temperature(k): 5000 — 9500 (choice by user)

Physical density: 360000 pixels/m²

Whole display flatness: ≤ 1mm juncture

Best view distance: ≥ 2m

Best view angle: Horizontal ±80°, Vertical ±80°

Storage temperature: -35℃ ～ +85℃ Working temperature: -20℃ ～ +50℃

Driving method: Constant driving current

Refresh frequency: ≥ 3000Hz

Frame rate: ≥ 60Hz

Humidity(RH): ≤ 90 ～ 95%

Protection grade: IP64

Working Voltage: DC 5V

Power supply: AC110 / 220V, 50/60Hz

Average power consumption: 350 w/m²

Max power consumption: 700 w/m²

MTBF: 10000 hours

Screen lifetime: 100000 hours

Control

system

Control system: Linsn/Nova

Signal interface: DVI

Communication distance: Internet cable: ≤ 120m   Fiber cable: 1000m

Signal transfer mode: Pixels to pixels display synchronized
